Industrial High Power Femtosecond Laser

Industrial High Power Femtosecond Laser —with IR, Green, and UV Options

  • Optical fiber seed + solid state amplification

  • Pulse energy:> 2 mJ

  • Power:>300 W @ IR, >80 W @ green, >30 W @ UV

  • Pulse duration: <600 fs @ lR, <500 fs @ green, <500 fs @ UV

  • Beam quality: M²≤1.3; Beam circularity: 90% (both near and far fields)

  • industrial high power femtosecond laser —with ir, green, and uv options 1
  • industrial high power femtosecond laser —with ir, green, and uv options 2
0
YEARS EXPERIENCE
0
EXPERIENCED EMPLOYEES
0
R&D AND SUPPORT ENGINEERS
0
GLOBAL CUSTOMERS

IR Femtosecond Laser Specifications

Product ModelIR Femtosecond Laser-1030-10IR Femtosecond Laser-1030-50IR Femtosecond Laser-1030-80IR Femtosecond Laser -1030-300
Center Wavelength1030+5 nm
Power10 W@ 100 kHz50 W@200 kHz80 W@200 kHz300 W@1 MHz
Repetition Rate1 Hz~2 MHz
Pulse Energy100 μJ250 μJ400 μJ2 mJ
Power stability<1.0%@8 hours, rms
Pulse Duration<300 fs<600 fs<400 fs
Beam QualityTEMoo, M²≤1.2TEMoo, M²≤1.3
Beam Circularity>90%
Burst Mode1~5
Dimensions800*432*149 mm³980*560*153 mm³
Trigger ModePSO、POD、Gate mode,and TTL trigger
External Power Control0-5 V
Warm-up Time≤15 min
Environment Humidity<60% RH@25°C
vironment Temperature22-30℃
CoolingWater cooling

Green Femtosecond Laser Specifications

Product ModelGreen Femtosecond Laser-515-30Green Femtosecond Laser-515-80
Center Wavelength515±3 nm
Power30 W@ 200 kHz80 W@ 200 kHz
Repetition Rate1 Hz~1 MHz1 Hz~2 MHz
Pulse Energy150 μJ400 μJ
Power stability<1%(8 hours, RMS)
Pulse Duration<500 fs
Beam QualityTEMoo, M²≤1.3
Beam Circularity>90%
Burst Mode1~5
Dimensions800*432*149 mm³
Trigger ModePSO、POD、Gate mode,and TTL trigger
External Power Control0-5 V
Warm-up Time≤15 min
Environment Humidity<60% RH@25°C
vironment Temperature22-30℃
CoolingWater cooling

UV Femtosecond Laser Specifications

Product ModelUV Femtosecond Laser-343-30
Center Wavelength343±1 nm
Power30 W@1 MHz
Repetition Rate1 Hz~2 MHz
Pulse Energy30 μJ
Power stability<1%(8 hours,RMS)
Pulse Duration<500 fs
Beam QualityTEMoo, M²≤1.3
Beam Circularity>85%
Burst Mode1~5
Dimensions800*432*149 mm³
Trigger ModePS0、POD、Gate mode,and TTL trig ger
External Power Control0~5V
Warm-up Time≤15 min
Environment Humidity<60%RH@25 °C
Environment Temperature22~30°C
CoolingWater cooling

achieves a compact footprint byintegrating optical,mechanical, and electrical modules. The products include 10-300 W IR femto-second laser,15-80 W green femtosecond laser, and 30 W UV femtosecond laser.
The product family is controlled by a PC software, which follows the industrialdesign standard, supports a user-friendlyinterface, and has passed 24/7industrial field tests.

Product Pictures

industrial high power femtosecond laser —with ir, green, and uv options 5

Product Applications

industrial high power femtosecond laser —with ir, green, and uv options 4
●OLED cutting                                                                ●Glass cutting & marking
●Flexible material cutting                                             ●LTCC driling
●Metal drilling                                                                 ● Sapphire cutting
●LCP 5G antenna cutting                                              ●Ceramic processing
●PCB processing                                                             ●Film cutting
●Wafer dicing                                                                  ●Laminated power battery positive electrode plate
●Photovoltaic panel scribing
