Laser Wavelength | 1030-1090nm | 1030-1090nm | 1030-1090nm |
Fiber Connector Type | QBH/QD/Q+/LOE | QBH/QD/Q+/LOE | QBH/QD/Q+/LOE |
Laser Power Handling | ≤15KW | ≤20KW | ≤30KW |
NA (Numerical Aperture) | ≤0.13 | ≤0.13 | ≤0.13 |
Magnification Ratio | M=2.0 | M=2.0/2.5 | M=3.0 |
Focusing Range | +15mm— -30mm(M=2.0) +9mm—-11mm(M=1.5) |
+25mm— -30mm(M=2.0) +28mm— -38mm(M=2.5) |
+33mm— -66mm(M=3.0) |
Spot Centering Adjustment Range | ± 1.5mm | ± 1.5mm | ± 1.5mm |
The high-power fiber laser intelligent cutting head offers 15KW, 20KW, and 30KW options with an optical magnification range of 1.5 to 3.0. It is designed for both flat and perforation cutting. The cutting head supports either non-bus or ECAT bus control modes and is compatible with various systems worldwide. Featuring multiple fiber interfaces such as QBH, QD, Q+, and LOE, it can be integrated with mainstream lasers. Real-time monitoring data can be accessed directly through CNC systems, ensuring efficient and precise metal sheet cutting for industrial applications. It is widely used in industries like sheet metal processing, shipbuilding, construction machinery, hardware appliances, and automotive manufacturing.
