| Model | J4410F-L1000 | J4410F-L500 | J4410F-C50 |
| Sensor Type | Linear Displacement Sensor | Potentiometer / Angular Displacement Sensor | |
| Processing Dimension | L=25-1000mm | L=20-500mm | φ=10-70mm |
| Independent Linearity | 20-50mm:≤±0.2% | 20-50mm:≤±0.25% | 10-25mm:≤±0.15% |
| 50-125mm:≤±0.1% | 50-150mm:≤±0.2% | 25-70mm:≤±0.1% | |
| 125-1000mm:≤±0.05% | 150-500mm:≤±0.1% | ||
| Target Precision | ±0.2% | ||
| Measuring Range | 100K-500KΩ | ||
| Measuring Precision | ＜160KΩ: ±0.02% | ||
| ＞160KΩ: ±0.04% | |||
| Software | Self-developed Trimlab | ||
| Operation System | Win7/Win10 | ||
| Language | Multilingual | ||
| Software Customization | Optional | ||
| Power Supply | 220V 50HZ 10A | ||
| Gas Pressure | 0.4-0.6Mpa | ||
| WorkingTemperature | 24±4℃ | ||
The RD-C50 Angular Displacement Potentiometer Tester is a high-precision comprehensive testing instrument. It is used to test and measure various parameters of angular displacement potentiometers. The development of this equipment refers to relevant theoretical foundations such as GJB1865A-2015 General Specification for Non-Wirewound Precision Potentiometers, GBT-15298-94, etc. It is accompanied by proprietary measurement software (DsmLabV1.0) with intellectual property rights. This software enables precise measurement of various technical parameters of angular displacement potentiometers, meeting the measurement needs of potentiometer production and quality control in the defense industry.
Key Features
- Target Precision: ±0.2%, ensuring high accuracy for critical testing applications.
- Wide Measuring Range: 100KΩ to 500KΩ, accommodating a broad spectrum of potentiometer types.
- High Measurement Precision: <160KΩ: ±0.02%, >160KΩ: ±0.04%, providing consistent results for both low and high-resistance potentiometers.
- Custom Software Support: Self-developed Trimlab software for streamlined testing, analysis, and reporting.
- Multilingual Support: The software is available in multiple languages, making it adaptable for global markets.
- Flexible Power Supply: 220V 50HZ 10A, suitable for a wide range of industrial environments.
- Custom Software Customization: Optional software customization based on customer needs, ensuring seamless integration with specific testing processes.
- Gas Pressure Control: Ensures optimal working conditions (0.4-0.6Mpa) for accurate testing performance.
- Temperature Stability: Operates effectively within a working temperature range of 24±4℃.
Technical Specifications
| Parameter | Specification |
|---|---|
| Target Precision | ±0.2% |
| Measuring Range | 100KΩ-500KΩ |
| Measuring Precision | <160KΩ: ±0.02%, >160KΩ: ±0.04% |
| Software | Self-developed Trimlab |
| Operation System | Win7/Win10 |
| Language | Multilingual |
| Software Customization | Optional |
| Power Supply | 220V 50HZ 10A |
| Gas Pressure | 0.4-0.6Mpa |
| Working Temperature | 24±4℃ |
Applications
- Automotive Industry: Testing displacement sensors in car components, ensuring safety and precision.
- Aerospace: Essential for testing critical components used in aviation, such as flight controls and navigation systems.
- Industrial Machinery: Ideal for calibrating machinery sensors and ensuring operational accuracy on production lines.
- Research & Development: Widely used in R&D for developing new displacement potentiometers and testing prototypes.
Why Choose RD-C50 Angular Displacement Potentiometer Tester?
- We are a trusted angular displacement potentiometer tester manufacturer, offering custom solutions tailored to meet your specific requirements.
- Our testers deliver high precision and reliability, making them ideal for industries with demanding testing needs.
- We provide OEM and wholesale options, offering competitive pricing for bulk orders, ensuring cost-effective solutions for businesses.
- Designed with industrial-grade durability, our testers are built to perform in the most challenging environments.
- Comprehensive after-sales support, including technical assistance, software updates, and warranty services.
Contact Us Today
If you’re looking for a high-precision RD-C50 Angular Displacement Potentiometer Tester, contact us today. We offer custom solutions, OEM options, and competitive prices to meet your specific testing needs. Whether you’re looking for a single unit or bulk orders, we can fulfill your requirements with fast delivery and exceptional service.
